Customized Thickened Drilling Bucket Bullet Teeth Rock Rools Drilling Equipments

Brand Name : APIE

Model Number : K2-1

Certification : CE and ISO9001

Place of Origin : Jiangsu, China

MOQ : 1 sets

Price : $1000+

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 15 sets/month

Delivery Time : 10-15days

Packaging Details : One is nude packing and overall transport by sea with roll-on -roll ship.( L*W*H=9150*2600*3250mm); The other is host in the flat rack; kelly bar and bucket is also nude, meanwhile four wooden case which is put with mast, power head, follow-up frame and ma

Product name : core barrel with bullet teeth

Showroom Location : Viet Nam, Peru, Indonesia, Mexico, Russia, Thailand, Australia

Material : Steel GB-Q345B

Drilling diameter : 600-3000mm or as required

Color : Black or as required

Type : Core barrel

Teeth Type : Bullet teeth

Application : Medium weathered rock, bedrock;

Drilling core barrel : Piling rotary rigs drilling tools core barrel with BK47 bullet

Processing type : Forging

Contact Now

Rock rools drilling equipments Customized Thickened drilling bucket bullet teeth

Product Feature

1.Cutting ring with staggered arrangement of round shank chisels
2.Chisel holders are welded to the base body. The round shank chisels can be easily replaced
3.Kelly box: 130mm,150mm,200mm(optional)
4.Barrel adopts spiral wear-resistant strips for anti-attrition to prolong the service life
5.Many alloy teeth are used for higher drilling efficiency
6.Heightened design with high construction efficiency, reducing construction cost

Product Description

1.Core barrels are used to cut an annular ring in rock or concrete or reinforced concrete.
2.The center core of the rock or concrete is usually crushed with rock auger. The most important advantage of a core barrel is that it assists to concentrate the torque and crowd force on a small ring of cutting teeth.

Technical Specification of core barrel with bullet teeth
drilling Dia. Shell HIT Shell Thickness Teeth.No. Weight
(mm) (mm) (mm) (kg)
600 1200 16 6 520
800 1200 16 9 672
900 1200 16 10 750
1000 1200 16 11 847
1200 1200 16 13 1010
1500 1200 16 16 1370
1600 1200 16 17 1493
1800 1000 20 19 1841
2000 800 20 21 1852
2200 800 20 23 2329
2500 800 20 27 2705
2800 800 20 30 3200
3000 800 20 32 3800


Product Details

Customized Thickened Drilling Bucket Bullet Teeth Rock Rools Drilling Equipments

Customized Thickened Drilling Bucket Bullet Teeth Rock Rools Drilling Equipments

Customized Thickened Drilling Bucket Bullet Teeth Rock Rools Drilling Equipments

FAQ

1: How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment

2: What can you buy from us?
Rotary Drilling Rig,Hydraulic Pile Breaker,Clamshell Telescopic Arm, drilling tools

3: What's your service ?

We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
